32A SEA J1772 Type 1 AC EV Charging Connector
Product Introduction
The charging speed depends on three components - the charging station, which is the source of power, the charging cable and the on-board charger. You should select right EV charging connector to fit this system. Type 1 is a single-phase plug and is standard for EVs from America and Asia (Japan & Korea). It allows you to charge your car at a speed of up to 7.4 kW, depending on the charging power of your car and grid capability. This plug is designed for use in EV charging cables and will mate with any J1772 specified socket. It’s rated at 70A and therefore are suitable for 16 and 32 amp or higher current applications as per the IEC 61851-2001 / SAE J1772-2001 standard. Shell colors are black, white, or customized.
Applicable Models
The Type 1 plug is compatible with all Japanese and USA-built EVs (except Teslas) eg:
All Nissan EVs
Mitsubishi i-MiEV / Outlander
All Vauxhall EVs and Plug-in Hybrids
Citroen C-Zero
Peugeot Ion
All Toyota EVs and Plug-in Hybrids
Renault Kangoo / Fluence
Kia Soul (not Optima - Type 2)
Fisker Karma
Ford C-MAX Energi / Ford Focus EV
Lightning EV
Mercedes Vito E-Cell Van
l MIA Electric
l Toyota Prius PHEV
Product Features
For use with any SAE J1772 compatible electric vehicle;
Nice shape, hand-held ergonomic design, easy to use;
lProtection class: IP67(in mated conditions);
lReliability of materials, environmental protection, abrasion resistance, impact resistance, oil resistance and Anti-UV.
Mechanical properties
Mechanical life: no-load socket in/pull out >10000 times
Insertion and coupled Force: 45N<F<80N;
Operating temperature: -30°C ~ +50°C
Materials
Shell material: Thermoplastic (Insulator inflammability UL94 V-0);
Contact Pin: Copper alloy, silver or nickel plating;
Sealing gasket: rubber or silicon rubber.
Installation & Storage
Please match your charging point correctly;
Store it in waterproof place to avoid short circuit during use.
