16A 5m IEC 62196-2 Type 2 EV Electric Car Charging Cable 5m 1Phase Type 2 EVSE Cable

Get A Quote Download as PDF

Details

Product Tags

Product Introduction

Fast Charge your EV at 3.7kW or 7.4kW (8 hours or 4 hours respectively for a 30kw Battery).

Strong Impact resistant from a 1 meter drop onto concrete. Dust and splash-resistant with an IP Rating* of 54 when mated.

Comfortable The contoured grip fits in your palm comfortably allowing for easy insertion and removal of the plugs.

Compatible Suitable for all Type 2 electric vehicles including Tesla, Jaguar, Renault, Kia, BMW, Ford, Audi, Vauxhall, Nissan, MG, Mercedes, Hyundai. 32A cables are backward compatible with 16A supplies.

Product Features

Installation Guide

1.Park the car at the charging point and turn off the engine.

2.Insert the Type 2 male plug end into the charger’s outlet socket. Be sure to push firmly so the pins can fully locked.

3.Insert the Type 2 female plug end into your car’s inlet socket. Be sure to push firmly so the pins can fully locked.

4.Lock your car and the cable if the car supports.

5.After charging is complete, remove the plug from the car firstly and then remove the male plug from the charging unit.

Compatible Cars - Please check your car's charging port before you order. If the port has 7 holes, it is a Type 2 car and needs a Type 2 to Type 2 charging cable. If the port has 5 holes, it needs a Type 1 to Type 2 charging cable.

Compatible Charging Units - Please use it on Type 2 (IEC 62196-2) socketed charging point which has 7 holes.

Plugged Directly - This charging cable must always be plugged directly into a charge point socket and can't be used as an extension or an adapter to a tethered lead.

Specification

Rated Current	16Amp / 32Amp
Operation Voltage	AC 250V
Insulation Resistance	＞1000MΩ ( DC 500V )
Withstand Voltage	2000V
Pin Material	Copper Alloy, Silver Plating
Shell Material	Thermoplastic,Flame Retardant Grade UL94 V-0
Mechanical Life	No-Load Plug In / Pull Out ＞10000 Times
Contact Resistance	0.5mΩ Max
Terminal Temperature Rise	＜50K
Operating Temperature	-30°C~+50°C
Impact Insertion Force	>300N
Waterproof Degree	IP55
Cable Protection	Reliability of materials,antiflaming,pressure-resistant, abrasion resistance,impact resistance and high oil

Plug Standard	Current	Phase	Power
TYPE2-TYPE2	16A	1-Phase	3.6kW
TYPE2-TYPE2	16A	3-Phase	11kW
TYPE2-TYPE2	32A	1-Phase	7.2kW
TYPE2-TYPE2	32A	3-Phase	22kW
TYPE1-TYPE2	16A	1-Phase	3.6kW
TYPE1-TYPE2	32A	1-Phase	7.2kW
